Technical specifications
08
7. Technical specifications
USB Port
USB 3.0-Compliant x HCI Host Controller
PCI-E x1 Gen2 Interface
One downstream port
Specifications for power supply
USB power supply：5V/1500mA MAX
External power supply：DC 9~12V，≥1200mA
Power supply port: outer diameter 5.5mm inner diameter 2.1mm (+ for inner, - for outer)
Notice: Don't connect to the power above 12V, or will damage the device!
Boundary dimension
114 x 64 x 23 mm (including protruding parts)
For purpose of improvement design and specifications are subject to change without
notice.
