A Open HARDWARE FOR STEP 6.
B Attach the PEDAL ARM COVERS (18) to the LEFT
PEDAL ARM (5) using 4 SCREWS (Q).
C Connect the CABLES (8) to the CONSOLE (20) and carefully
tuck the excess cable into the CONSOLE MAST (21).
D Attach the CONSOLE (20) to the CONSOLE MAST (8) using 4 BOLTS (R).
A50 SHOWN
A30 / A50 ASSEMBLY COMPLETE!
Hardware For Step 6
Description Qty
Q
R
Screw
Bolt
4
4
Note: Be careful not to pinch
any wires while attaching the
console.
