7
3 4
Pink Hardware Bag
Description Qty
Screw (M5x0.8Px16L) 2
Green Hardware Bag
Description Qty
Socket Head Bolt
Flat Washer
Hex Nut
(M10x1.5Px100L)
(Φ10.2xΦ20x2.0T)
(M10) Class 10
1
2
1
Yellow Hardware Bag
Description Qty
Screw (M5x0.8Px10L) 5
Note:
Use torque wrench and
tighten to (70 N-m - 90 N-m)
