Matrix Asset Management User Manual

5
SETTING UP MATRIX CARDIO EQUIPMENT FOR ASSET MANAGEMENT (7X AND 7XE CONSOLES):
1 Enter Service Mode (press ENTER, 3, 0, 0, 1, ENTER on the lower keypad).
a. Select Setup (may already be selected).
b. Select Serial Number.
c. Enter the serial number of the console and frame if not already entered (only the last 9 digits of the serial number are entered).
d. Select Date & Time.
e. Enter the date and time if not already entered.
f. Press Home to return to the standard display picture.
2 Enter Engineering Mode (press ENTER, 2, 0, 0, 1, ENTER on the lower keypad).
a. Select Club ID.
b. Enter your Club ID (this should be 6 digits, for example if your Club ID is 110, you will enter 000110).
c. Press Home to return to the standard display picture.
3 Activate the Radio Connection (press ENTER, 2, 0, 0, 4, ENTER on the lower keypad).
4 Reboot the unit.
5 Enter Manager Mode (press ENTER, 1, 0, 0, 1, ENTER on the lower keypad).
a. Select About (may already be selected).
b. Select Software Versions.
c. Check the column on the right side of the screen to make sure that a Radio version is listed. If a Radio version is not listed, check
the connection of the radio at the Upper Control Board. Then repeat steps 3-5.
d. Press Home to return to the standard display picture.
6 Press ENTER, 4, 0, 0, 8, ENTER on the lower keypad. This screen will show you the current information regarding the RAP. Look for a
current date which indicates that the units are communicating with the RAP. Press ENTER, 4, 0, 0, 8, ENTER to return to the standard
display picture.
a. If the date shown is not current, check the connection of the RAP and the radios in the console of the cardio units. Reboot both
RAP and equipment and repeat step 6.
SETTING UP MATRIX CARDIO EQUIPMENT FOR ASSET MANAGEMENT (5X CONSOLE):
1 Enter Engineering Mode (simultaneously press and hold both Level keys for 3-5 seconds or the Incline Up and Speed Down keys on
treadmills).
a. Manager Mode will appear first. Press any Arrow key until Engineering Mode is displayed.
b. Press ENTER.
c. Press any Arrow key until Serial Number is displayed.
d. Press ENTER.
e. Enter the serial number of the console if not already entered (only the last 9 digits of the serial number are entered).
f. Once the serial number of the console is recorded, press ENTER.
g. Press any Arrow key until Club ID is displayed, and then press ENTER.
h. Enter the Club ID.
i. Press ENTER.
j. Press and hold the HOME key until the console returns to the standard display picture.
2 Activate the Radio Connection (press 2, 0, 0, 4, ENTER on the keypad).
3 Reboot the unit.
4 Enter Manager Mode (simultaneously press and hold both Level keys for 3-5 seconds or the Incline Up and Speed Down keys on treadmills).
a. When Manager Mode is displayed, press ENTER.
b. Press any Arrow key until Software is displayed.
c. Press any Arrow key to scroll through the listed software versions. There should now be a version shown for RF Radio. If a Radio
version is not listed, check the connection of the radio at the Upper Control Board. Then repeat steps 2-4.
d. Press Home (or press and release the Emergency Stop on treadmills) to return to the standard display picture.
SECTION A: SETUP AND INSTALLATION INSTRUCTIONS
