INCLUDED FASTENERS
6mm ALLEN WRENCH
5mm ALLEN WRENCH
REQUIRED TOOLS
Prior to assembling the unit, unpack all of the contents
of the box and make sure that all necessary components
are present. Review the contents of the hardware
package for completeness.
Contact Matrix Customer Service at 1(866) 693-4863 to
report any missing items.
Please make sure that the power plug is not plugged into
the wall outlet while completing the following procedure.
To ensure correct assembly of the unit, carefully read and
follow all assembly steps.
BEFORE YOU BEGIN
Qty: Sketch: Part Name: Bag:
4
SOCKET HEAD BOLT
(M8x25L)
Black
20
SOCKET HEAD BOLT
(M8x20L)
Blue
2
SOCKET HEAD BOLT
(M8x35L)
Green
3
SOCKET HEAD BOLT
(M8x16L)
Green
4
SOCKET HEAD BOLT
(M8x16L)
Blue
4 ARC WASHER Blue
8 FLAT WASHER Blue
5 FLAT WASHER Green
To Next Page
