Matrix C7xe User Manual

13
ASSEMBLY STEP 3
 Remove the five pre-attached console screws
from back of console.
 Carefully connect all wires coming from the
mast to the inside of the console.
Note: Depending on the console, not all cables
coming from the mast will need to be connected.
 Attach console to console mast using
provided bolts. Secure tightly, being careful
not to pinch any wires.
For C3x, skip page 14 and continue on page 15.
SOCKET HEAD BOLT(M5x12L)
5
CONTENTS ARE PRE-ATTACHED:
