17
Z05
Z11
Z27
Z13
Flat Washer (Φ10)
Screw (M10x110L)
Screw (M10x40L)
Nut (M10)
NOTE:
Do not completely tighten hardware until final step
Assembly laying down for step 3.
4
2
4
2
Item Description Qty
Existing wall-mounted upright
Z13
Z05x2
Z27x2
Z11
Z13
Z05x2
Z27x2
Z11
GFTEXP
Expansion
Step 3 of 5
