18
Existing wall-mounted upright
placed at end of expansion
Existing installed
wall-mount
Z26
Z05
Z24
Z13
Z12
Screw (M10x75L)
Flat Washer (Φ10)
Screw (M10x155L)
Nut (M10)
Screw (M10x95L)
2
16
8
8
2
Item Description Qty
NOTE:
Do not completely tighten hardware until final step
Z12x2
Z13x2
Z05x4
Z24x2
Z24x2
Z05x4
Z26x2
Z13x2
Z13x2
Z05x4
Z24x2
Z24x2
Z13x2
Z05x4
GFTEXP
Expansion
Step 4 of 5
