Matrix CONNEXUS Series

19
Z06
Z05
Z27
Z25
Z01
Screw (M8x25L)
Flat Washer (Φ10)
Screw (M10x40L)
Screw (M10x25L)
Screw (M10x15L)
NOTE:
Tighten hardware from steps 1–3 using the
following Torque Values on page 10.
8
6
2
4
1
Item Description Qty
Z05x2
Z27x2
Z01
Z06x4
Z05x2
Z25x2
Z06x2
Z05x2
Z25x2
Z06x2
GFTEXP
Expansion
Step 5 of 5
