9
NOTE:
Tighten hardware from steps 1–3 using the
following Torque Values on page 6.
Z06
Z05
Z27
Z25
Z01
Screw (M8x25L)
Flat Washer (Φ10)
Screw (M10x40L)
Screw (M10x25L)
Screw (M6x15L)
8
12
4
8
4
Item Description Qty
Z01
Z05x2
Z27x2
Z01
Z27x2
Z05x2
Z01
Z06x2
Z25x2
Z05x2
Z06x2
Z25x2
Z05x2
Z01
Z06x2
Z05x2
Z25x2
Z05x2
Z25x2
Z06x2
GFTFS
Free Standing
Step 3 of 3
