8
Z26
Z05
Z24
Z13
Screw (M10x75L)
Flat Washer (Φ10)
Screw (M10x155L)
Nut (M10)
8
16
8
8
Item Description Qty
NOTE:
Do not completely tighten hardware until final step
Z05x4
Z24x2
Z26x2
Z05x4
Z24x2
Z13x2
Z26x2
Z24x2
Z05x4
Z24x2
Z05x4
Z13x2
Z26x2
Z13x2
Z13x2
Z26x2
GFTFS
Free Standing
Step 2 of 3
