19
Z10
Z12 Flat Washer (M10)
Nylon Nut (M10) 4
8
Z14
Z15 Screw, Round-HS (M10x25L)
Screw, Round-HS (M10x80L) 4
4
Item Description Qty
Frame Detail
Z22 Arc-flat Washer 4
Z12
Z10
Z22
Z15
Z14
Z12
G3-MS80
8 Stack - Step 2 of 3
Sample Conguration
