Matrix G3-MS52

16
Adjustabel Pulley Right
G3-MS24
Z12
Z10
Z22
Z15
Z14
Z12
Z10
Z22
Z02 Z16Z09 Z22
Z02
Z09
Z10
Z12
Z14
Z15
Z16
Z22
Flat Washer (M8)
Screw, Oval-HS(M10x100L)
Nylon Nut (M10)
Flat Washer (M10)
Screw, Round-HS(M10x80L)
Screw, Round-HS(M10x25L)
Screw, Oval-HS(M8x25L)
Arc Washer
4
4
8
8
4
4
4
12
Item Description Qty
Frame Detail
G3-MS50
5 Stack - Step 2 of 3
Sample Conguration
