17
ENGLISH
Z12
Z10
Z22
Z15
Z14
Z12
G3-MS80
8 Stack - Step 2 of 3
Sample Configuration
DESCRIPTION QTY
Z10 Nylon Nut (M10) 4
Z12 Flat Washer (M10) 8
Z14 Screw, Round-HS (M10x80L) 4
Z15 Screw, Round-HS (M10x25L) 4
Z22 Arc-flat Washer 4
