G7-S78 GLUTE
UNPACKING G7-S78 GLUTE
Thank you for purchasing a MATRIX Fitness product. This machine is an EN957-1 and EN957-2 complaint Class S product. Your
MATRIX G7-S78 GLUTE is inspected before it is packaged. It is shipped in multiple pieces to facilitate the compact
packaging of the machine. Prior to assembly, confirm all the components by matching them with the exploded diagrams. The
weight stack is shipped in separate packaging to reduce the weight of this box. Carefully unpack the unit from this box and
dispose of the packing materials in accordance with your local laws.
CAUTION
The weight of the G7-S78 GLUTE is 372 lbs. (169 kg) not including the weight stack. The weight stack tower is packaged
completely assembled for ease of installation; use extra caution when removing from its pallet during assembly. The weight stack
for this machine is 199 lbs. (90.2 kg). To avoid injury to yourself and prevent damage to the frame components, be sure to have
proper assistance removing the frame pieces from this box. Please be sure to install the equipment on a stable base, properly
level the machine and leave at least two feet of clearance to enter and exit the machine. Maximum user weight for this machine
is300 lbs.
INCLUDED TOOLS REQUIRED FOR ASSEMBLY
3MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench
5MM L-Shaped Allen Wrench
6MM L-Shaped Allen Wrench
8MM L-Shaped Allen Wrench
10MM L-Shaped Allen Wrench
Phillips Screwdriver
8MM Open-End Wrench
17MM Open-End Wrench
If any items are missing please contact your country’s local MATRIX dealer for assistance.
0mm 10 20 30 40 50 60 70 80 90 100 1
10 120 130 140 150 160
Step 1
2Screw (M10X30L)Z02
Screw (M10X85L)
Nylon Nut (M10)B20
Screw (M8X75L)Q11
Lock Washer
Flat Washer (M10)
Z03
B24
Z09
QtyDescriptionItem
8
4
4
4
2
Frame Detail
60
wing and cover re-assembly.Q11 bolts won't be used anymore for the
then take apart the front and rear shields.Lift the aluminum wing and top cover,
Q11
Q11
Q11
Q11
B20
B24
Z02
Z03
Z03
B24
B20
B24
B24
Z03
Z09
Step 2
4Screw (M10X80L)Z08
4
8
16
4
16
Item Description Qty
Z01
B24
Z03
Flat Washer (M10)
Lock Washer
Z23 Arc-flat Washer
B20 Nylon Nut (M10)
Screw (M10X75L)
Z02 Screw (M10X30L) 4
Connect Detail
Z01
Z03
B24
B24
B20
B20
B24
B24
Z03
Z01
Z02
Z23
Z23
Z02
Z02
Z23
Z08
Z03
B24
B20
B20
B24
B24
B24
Z03
Z08
Step 3
2
2
2
2
2
Item Description Qty
C11
C54
M05
Fixing Plate
Thick Fixing Sleeve
C53 Cap End
C55 Internal C Clamp
Thin Fixing Sleeve
C49 Axle Sleeve 4
Pedal Detail
C11
C11
C49
C49
C53
C55
C54
M05
C49
C49
M05
C54
C55
C53
Step 4
1Fixing PinZ102
Z14 1E Clip
2
Stopper Plate 1
1Nylon Nut (M10)
F06
B20
Small CamF05
Big CamF12 1
1
4
1
2
5
Item Description Qty
Z10
B24
F07
Flat Washer (M10)
Screw (£X10XM8X46L)
F14 Flat Washer (M8)
F13 Fixing Block
Screw (M10X110L)
C52 Pulley Cover 1
Cable Routing Detail
F05
F12
F13
Z102
Z14
F13
F06
F07
F07
F14
F07
B20
B24
B24
F07
B24
B24
F07
C52
Z10
F13Cable
Step 5
1
4
6
Item Description Qty
C51
Z06
Z05
Screw (M10X25L)
Screw (M10X20L)
Special Screw
C59 Flat Washer (M8) 1
Pad Detail
C51
C59
Z06
Z05
Z05
Hand Pad
Hand Pad
Chest Pad
Step 6
Fixing Plate
Rubber Pad
4
Item Description Qty
Z12 Screw (M10X60L)
Shield Detail
Lift the wing and top cover ,then assemble the front and rear shields to the frame.
60
Z12
Z12
Z12
Z12
