48
6. Spark plug
7. Oil dipstick
8. Lever for adjusting the cutting height
9. Flap for the grass basket
10 Grass basket
11. Quick Handle lock for upper
12. Quick Collection
13. Screw for cable holder
14. 2x cable ties
15. Lower push bar
16/17. Fastening screws for bottom push bar
18/19. Fastening nuts for bottom push bar
20. Starter cord guide
3. Proper operation
The petrol lawn mower is intended for private
use i.e. for use in gardening environments.
Private use of the lawn mower refers an annual
operating time generally not exceeding that
of 50 hours, during which time the machine is
primarily used to maintain small-scale, residential
lawns and home/hobby gardens. Public
facilities, sporting halls, and agricultural/forestry
applications are excluded.
Please note that our equipment not intended for
use in commercial, trade or industrial applications
were designed. We assume no Warranty if the
device used in commercial, Trade or industrial
businesses or for equivalent purposes.
The operating instructions as supplied by the
manufacturer must be kept and referred to in
order to ensure that the lawn mower is properly
used and maintained. The instructions contain
valuable information on operating, maintenance
and servicing conditions.
Important! Due to the high risk of bodily injury
to the user, the lawn mower may not be used
to trim bushes, hedges or shrubs, to cut scaling
vegetation, planted roofs, or balcony-grown
grass, to clean (suck up) dirt and debris o
walkways, or to chop up tree or hedge clippings.
Moreover, the lawn mower may not be used as a
power cultivator to level out high areas such as
molehills.
For safety reasons, the lawn mower may not
be used as a drive unit for other work tools or
toolkits of any kind.
4. Technical data
Engine type:
OHV , Viertaktmotor , Luftkühlung ; 139 cc
Engine power: Max.2,5 Kw
Working speed: 2800 min
-1
Fuel: standard petrol
Tank capacity: approx. 0.8 l
Engine oil: approx. 0.6 l / 10W30
Electrode spacing: 0.7 – 0.8 mm
Cutting height adjustment: central, (25-75 mm)
Cutting width: 400 mm
L
pA
sound pressure level: 82,5 dB(A) (K=3dB(A))
L
WA
sound power level: 96 dB(A) (K=3 dB(A))
Vibration a
hw
3,469 m/s
2
(K=1.5m/s
2
)
Weight: 28,5 kg
5. Before starting the equipment
5.1 Assembling the components
Some parts of the mower come disassembled.
For quick and easy assembly, read and follow the
instructions below.
Important. You will need the following additional
tools (not supplied) for assembly, and also for
maintenance work:
• An open-ended wrench (10 mm)
• A ring wrench (12 mm)
• An open-ended wrench (13 mm)
• A at oil drip tray (for changing the oil)
• A 1 liter measuring jug (oil/petrol resistant)
• A petrol can (5 liters is sucient for approx. 6
operating hours)
• A funnel (suitable for the tank’s petrol ller neck)
• Household wipes (to wipe up oil/petrol residue;
