9
Wheel
Washer
Cotter pin
Wheel cover
On/O switch
Electrical connection
Check luminous indicator
Material expulsion
Knob
Filling hopper
Adjustable blade
Frame
Wheel axis
Spacer tube
1
2
3
4
5
6
7
8
9
10
11
12
13
14
