Matrix IC-MXEB-01 User Manual

Version 1.0 2013 IC-MXEB-01 Copyright by Indoorcycling Group GmbH 2013 | www.indoorcycling.com ENG 5
1
3 4
2
Assure that plastic gasket is placed between
stabilizer and frame.
Assure that plastic gasket is placed between
stabilizer and frame.
Assure that black rubber washer is placed
between upper frame and bolt/washer.
Assure that black rubber washer is placed
between upper frame and bolt/washer.
Please assure that nuts are tightened with signi cant strength to minimize loosening during use.
HOW TO ASSEMBLE Matrix E-Series
SW 17mm
SW 14mm
3mm
hand tight
2x
15mm Pedal
Wrench
1x
ENG ESP

Matrix IC-MXEB-01 Specifications

General

Brand	Matrix
Model	IC-MXEB-01
Category	Exercise Bike
Language	English
