HOW TO ASSEMBLE Matrix E-Series
SW 17mm
SW 14mm
3mm
hand tight
2x
15mm Pedal
Wrench
1x
Pedal marked R installed on right crank (clockwise). Pedal marked L installed on left crank
(counter-clockwise) Pedals must be fastened with signi cant strength to avoid loosening
with use of the Matrix E-Series.
