CHAPTER Ⅲ PARTS REPLACMENT
 Brake system replacement
1) Remove the lower brake kit
a) Loosen the M6 x 20 x 1.0P Allen bolts of the bell crank and brake pad.
b) Loosen the 2 M10 x 0.75P flat nuts.
c) Remove the lower brake kit.
2) Remove the upper brake rod assembly
a) Loosen the M6 x 55 x 1.0P Phillips bolt from the emergency brake handle.
b) Remove the upper brake system.
