2.3 ASSEMBLY STEPS
CHAPTER 2:
KranKcycle
™
specifications, parts and assembly steps
Secure BASE PLATE to BASE FRAME from step 3 with item 3-PHILLIPS HEAD
SCREW and PHILLIPS HEAD SCREW DRIVER.
Place SMALL BASEPLATE FRONT COVER and LARGE MAIN BASE PLATE on metal
frame.
STEP 3 STEP 4
