5
ENGLISH
ASSEMBLY
TOOLS REQUIRED:
F 4 mm Allen Wrench
F 5 mm Allen Wrench
F 6 mm Allen Wrench
F 13/17 mm Flat Wrench
F Phillips Screwdriver
UNPACKING
Unpack the equipment where you will be using it. Place the carton
on a level flat surface. It is recommended that you place a protective
covering on your floor. Never open box when it is on its side.
IMPORTANT NOTES
• All video and power outlets must be functional the day of delivery /
assembly of the product. The client is responsible for any additional
installation charges associated with return visits.
• During each assembly step, ensure that ALL nuts and
bolts are in place and partially threaded.
• Several parts have been pre-lubricated to aid in assembly and usage. Please do not wipe
this o. If you have diculty, a light application of lithium grease is recommended.
WARNING!
There are several areas during the assembly process that special attention must be
paid. It is very important to follow the assembly instructions correctly and to make
sure all parts are firmly tightened. If the assembly instructions are not followed
correctly, the equipment could have parts that are not tightened and will seem
loose and may cause irritating noises. To prevent damage to the equipment, the
assembly instructions must be reviewed and corrective actions should be taken.
NEED HELP?
If you have questions or if there are any missing parts, contact Customer Tech Support.
PARTS INCLUDED:
F 1 Elliptical Frame
F 1 Console Mast
F 1 Console Mast Boot
F 2 Upper Dual Action Arms
F 2 Lower Dual Action Arms
F 2 Handlebar Caps
F 2 Pedals with Inserts
F 2 Transport Handles
F 1 Power Cord
F 1 Hardware Kit
Console sold separately
PRODUCT SPECIFICATIONS
LIFESTYLE
CONSOLE TOUCH PREMIUM LED LED / GROUP TRAINING LED
Max User Weight 182 kg / 400 lbs
Product Weight 151 kg / 332.9 lbs 149.2 kg / 328.9 lbs 148.5 kg / 327.4 lbs
Shipping Weight 173 kg / 381.4 lbs 171.2 kg / 377.4 lbs 170.5 kg / 375.9 lbs
Overall Dimensions
(L x W x H)*
174.6 x 73 x 175.7 cm /
68.7” x 28.7” x 69.2”
* Ensure a minimum clearance width of 0.6 meters (24”) for access to and passage around MATRIX equipment.
Please note, 0.91 meters (36”) is the ADA recommended clearance width for individuals in wheelchairs.
