106
G. crankshaft, connecting rod and
piston assembly
G1 semi-round key 1
G2 needle bearing retainer 2
G3
crankshaft-connecting rod
assembly
1
G4 needle bearing 11X15X12.5 1
G5 piston 1
G6 piston ring 2
G7 clamp spring 2
G8 piston pin 1
H.ywheel and ignition coil assembly
H1 locknut M8 1
H2 spring washer 8 1
H3 ywheel 1
H4 ignition coil 1
H5 bolt M5X20 2
H6 protective sleeve 1
J. power assembly
J1 oil cap assembly 1
J2 short shock-absorbing seat 3
J3 screw M4X8 2
J4 pressing plate 1
J5 oil seal 15X35X5 1
J6 internal circlip 35 1
J7 deep groove ball bearing 6202 2
J8 screw M5X30 5
J9 left crankcase 1
J10 on-o switch seat 1
J11 on-o switch 1
J12 screw M5X10 1
J13 earthing 1
J14 dust-proof block 1
J15 pull rod of choke 1
J16 rod seat 1
J17 absorber 1
J18 oil seal 15X28X5 1
J19 screw ST4.2X9.5 1
J20 baer 1
