Page #10 background image
10
A
D
B A
A B
D
E
D
F
J
3 4
Step 3 Hardware
Description Qty
J Set Screw (ST4x20L) 1
Step 4 Hardware
Description Qty
A
B
D
E
F
Bolt (M10x20L)
Washer (Φ10.2)
Arc Washer (Φ10.5)
Bolt (M10x150L)
Nylock Nut (M10)
10
8
6
2
2
ENGLISH
