11
I
A
5 6
K L
N M
B
A
Step 2 Hardware
Description Qty
A
B
K
L
M
N
Bolt (M10x20L)
Washer (Φ10.2)
Bolt (M8x15L)
Washer (Φ8.5xΦ60)
Axle (Φ25.0x88)
POM Washer (41.8xΦ20.5)
1
1
1
1
1
2
ENGLISH
Step 5 Hardware
Description Qty
A
I
Bolt (M10x20L)
Washer (Φ10.5xΦ42)
1
1
