Matrix MD-S711 - Assembly Instructions; Step 7 Hardware and Seat;Plug Installation; Step 8 Hardware and Foot Pad Assembly

12
P
A
R
Q
O
P
O
B
7 8
Step 7 Hardware
Description Qty
B
O
P
Washer (Φ10.2)
Bolt (M10x25L)
Plug
4
6
2
Step 8 Hardware
Description Qty
A
P
Q
R
Bolt (M10x20L)
Plug
Bolt (M8x25L)
Washer (Φ8.4)
2
2
2
2
ENGLISH
