Page #13 background imageLoading...
Page #13 background image
13
S I
ATR
9 10
Q
R
Step 10 Hardware
Description Qty
Q
R
Bolt (M8x25L)
Washer (Φ8.4)
4
4
ENGLISH
Step 9 Hardware
Description Qty
A
I
R
S
T
Bolt (M10x20L)
Washer (Φ10.5xΦ42)
Washer (Φ8.4)
Wavy Washer (Φ30.5)
Nylock Nut (M8)
1
1
1
1
1
ASSEMBLY COMPLETE!
