Matrix Performance Upright Cycle User Manual

6
C
D
E
F
TOOLS REQUIRED:
F 4 mm Allen Wrench
F 6 mm Allen Wrench
F 8 mm Allen Wrench
F Flat Wrench (15mm/17mm 325L)
F Phillips Screwdriver
PARTS INCLUDED:
F 1 Main Frame
F 1 Rear Stabilizer Tube
F 1 Front Stabilizer Tube
F 1 Rear Frame Handle
F 1 Rear Frame Cover
F 1 Console Mast
F 1 Console Mast Cover
F 1 Seat
F 1 Front Shroud Cover
F 1 Pulse Grip Handlebars
F 1 Step Plate
F 1 Accessory Tray
F 2 Water Bottle Pockets
F 2 Pedals
F 1 Hardware Kit
F 1 Power Cord
Console sold separately
Upright Cycle Assembly
A
B
1
Hardware Qty
A
B
Bolt
Flat Washer
8
8
2
Hardware Qty
C
D
E
F
Bolt (black)
Screw
Bolt (chrome)
Tooth Washer
2
2
4
4
ENGLISH

Matrix Performance Upright Cycle Specifications

General

Brand	Matrix
Model	Performance Upright Cycle
Category	Exercise Bike
Language	English
