Matrix Performance Upright Cycle - RECUMBENT CYCLE ASSEMBLY

8
D
C
E
F
A
B
TOOLS REQUIRED:
F 4 mm Allen Wrench
F 6 mm Allen Wrench
F Flat Wrench (15mm/17mm 325L)
F Phillips Screwdriver
PARTS INCLUDED:
F 1 Main Frame
F 1 Rear Stabilizer Tube
F 1 Front Stabilizer Tube
F 1 Rear Frame Handle
F 1 Rear Frame Cover
F 1 Console Mast
F 1 Console Mast Cover
F 1 Console Handlebars
F 1 Front Shroud Cover
F 1 Seat Frame
F 2 Water Bottle Pockets
F 1 Seat Base
F 1 Seat Back
F 2 Pedals
F 1 Hardware Kit
F 1 Power Cord
Console sold separately
Recumbent Cycle Assembly
1
Hardware Qty
A
B
Bolt
Flat Washer
8
8
2
Hardware Qty
C
D
E
F
Bolt (black)
Screw
Bolt (chrome)
Tooth Washer
2
2
4
4
ENGLISH
