Page #6 background imageLoading...
Page #6 background image
6
C
D
A
B
ENGLISH
1
2
Hardware Qty
A
B
Bolt
Flat Washer
10
10
3
Hardware Qty
C
D
Bolt
Bushing
2
2
E
F
4
Hardware Qty
E
F
Bolt
Bushing
4
4
Pre-installed
Torque Value
40 Nm / 29 ft-lb
Torque Value
40 Nm / 29 ft-lb
Torque Value
40 Nm / 29 ft-lb
Performance only
Performance Plus
bolt locations
Performance
bolt locations
Peformance only

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Matrix PERFORMANCE and is the answer not in the manual?

Matrix PERFORMANCE Specifications

General IconGeneral
Motor3.0 HP
Running Area20" x 60"
Incline Range0% to 15%
Speed Range0.5 to 12 mph
Heart Rate MonitoringContact
