Matrix PERFORMANCE

7
I
J
K
ENGLISH
1
2
3
4
5
6
7
8
MCB Communication
Extension Power Wire
Emergency Stop
TV Power
Console Connect Wires
Ethernet
Coax
Ground Wire
1
8
7
6
5
4
3
2
H
G
5
Hardware Qty
G
H
Bolt
Flat Washer
6
6
7
Hardware Qty
J
K
Bolt
Screw
4
2
ASSEMBLY COMPLETE
Torque Value
40 Nm / 29 ft-lb
6
Hardware Qty
I Bolt 2
Torque Value
10 Nm / 7 ft-lb
Torque Value
40 Nm / 29 ft-lb
