Matrix Retail E50 User Manual

18
B .QUICK KEY
1) Remove the 3 screws from plastic housing. (Page 16, Fig-1)
2) Open the plastic housing.(Page16,Fig-2)
3) Disconnect the wires from HR plates and quick key connector. (Page16, Fig-3)
4) Remove the overlay from front plastic cover and slowly pull new keypad into the housing. (Page16, Fig-4)
5) Connect the wires to HR plates and quick key connector. (Page16, Fig-3)
6) Fasten 3 screws to the plastic housing, making sure wires are not being pinched.

Matrix Retail E50 Specifications

General

Brand	Matrix
Model	Retail E50
Category	Elliptical Trainer
Language	English
