4 5
READING RACK / TABLET HOLDER
HANDLEBAR / PULSE GRIPS
SAFETY KEY PLACEMENT
IN-REACH CONTROLS
CONSOLE MAST
POWER CORD / POWER SWITCH
MOTOR COVER
RUNNING BELT / DECK
SIDE RAIL
REAR ROLLER TENSION
& ADJUSTMENT BOLTS
CONSOLE
WATER BOTTLE HOLDER
CONSOLE BASE
CONSOLE MAST BOOT
HANDLEBAR SLEEVE
BASE FRAME COVER
TRANSPORT WHEEL
WHEEL LOCK
DECK RELEASE LATCH
TF50 SHOWN
TF30
TF50
TOOLS INCLUDED:
F 5 mm L Wrench
F 6 mm L Wrench
F 8 mm T Wrench
F Phillips Screwdriver
NEED HELP?
If you have questions or if there are any missing
parts, contact Customer Tech Support. Contact
information is located on the information card.
PARTS INCLUDED:
F 1 Treadmill Frame
F 2 Console Masts
F 2 Console Mast Boots
F 1 Console Base
F 1 Handlebar
F 2 Handlebar Sleeves
F 4 Handlebar Caps
F T30/T50: 4 Base Frame Covers
F T70/T75: 2 Base Frame Covers
F 1 Console Back Cover
F 1 Power Cord
F 1 Safety Key
F 1 Hardware Kit
F 1 Bottle of Silicone Lubricant
(for 2 applications)
Console sold separately
PARTS INCLUDED:
F 1 Treadmill Frame
F 2 Console Masts
F 2 Console Mast Boots
F 1 Console Base
F 1 Handlebar
F 2 Handlebar Sleeves
F 4 Handlebar Caps
F 2 Base Frame Cover Sets
F 1 Console Back Cover
F 1 Power Cord
F 1 Safety Key
F 1 Hardware Kit
F 1 Bottle of Silicone Lubricant
(for 2 applications)
Console sold separately
TF30 / TF50
5
T30 / T50 / T70 / T75
9
ASSEMBLY
ENGLISH
ENGLISH
