Matrix TOUCH XL User Manual

5
ENGLISH
D
E
Torque Value
77 Nm / 57 ft-lb
1
2
3
4
5
MCB Communication
Extension Power Wire
Ethernet
Coax
Ground Wire
1
2
5
4
3
Do not tighten bolts
until step 5 is complete.
C
B
A
2
Hardware Qty
A
B
C
Bolt
Spring Washer
Flat Washer
8
8
8
Torque Value
40 Nm / 29 ft-lb
Do not tighten bolts
until step 5 is complete.
ASSEMBLY
1
3
Hardware Qty
D
E
Bolt
Flat Washer
6
6
4

Matrix TOUCH XL Specifications

General

Brand	Matrix
Model	TOUCH XL
Category	Treadmill
Language	English
