Matrix TOUCH XL User Manual

6
ENGLISH
H
C
I
F
G
ASSEMBLY
5
Hardware Qty
F
G
Bolt
Flat Washer
2
2
Torque Value
F - 16 Nm / 12 ft-lb
30 Nm / 22 ft-lb
Tighten all bolts from
steps 2–3.
C
H
6
Hardware Qty
H
C
Bolt
Flat Washer
4
4
Torque Value
40 Nm / 29 ft-lb
7
Hardware Qty
H
C
I
Bolt
Flat Washer
Screw
4
4
2
1
4
3
6
2
5
7
1
2
3
4
5
6
7
MCB Communication
Extension Power Wire
Ethernet
Coax
Ground Wire
Emergency Stop
Console Connect Wires
Torque Value
H - 40 Nm / 29 ft-lb
ASSEMBLY COMPLETE
