Matrix U1x - Page 8

6
CHAPTER 2: Setup
Hardware Kit
(K)
(L)
(A)
(J)
(I)
(F)
(D)
(B)
(C)
(E)
(G)
(H)
A) Main Frame Assembly
B) Front Handlebar Set
C) Console Mast
D) Console Set
E) Seat
F) Seat Back
G) Seat Back Cover
H) Accessory Tray
I) Rear Handlebar Set
J) Rear Foot
K) Seat Frame
L) Hardware Kit
2.7 UNPACKING THE BIKES
The bike is carefully inspected before shipment so it should arrive in good operating condition. Matrix Fitness ships the unit in the following pieces:
R1x Recumbent Bike
