Matrix ULTRA Series Assembly Instructions

5
ENGLISH
A
D
B
B
C
3
Hardware Qty
A
B
C
D
Bolt (M10x80L)
Flat Washer (M10)
Nyloc Nut (M10)
Spring Washer (M10)
4
8
4
4
G
F
H
G
C
E
D
B
G
C
B
D
A
C
B
2
Hardware Qty
A
B
C
D
E
F
G
H
Bolt (M10x80L)
Flat Washer (M10)
Nyloc Nut (M10)
Spring Washer (M10)
Hex Bolt (M10x30L)
Bolt (M10x150L)
Arc Washer (M10)
Bolt (M10x180L)
4
12
8
8
4
2
8
2
D
B
A
B
C
ASSEMBLY
1
Hardware Qty
A
B
C
D
Bolt (M10x80L)
Flat Washer (M10)
Nyloc Nut (M10)
Spring Washer (M10)
4
8
4
4
Be sure to remove the insulating sheet
when installing the rep counter.
Do not fully tighten frame connectors until
assembly is complete. Vibra-Tite 135 Red Gel
or equivalent must be used on all fasteners
that are not assembled with Nyloc Nuts.
Pre-installed hardware
Pre-installed hardware
