Matrix UV Series - Connecting the Vacuum Pump System

VACUUM PUMP INSTALATION
STEP 7
azonprinter.com MATRIX GETTING STARTED
STEP 8
Printer back layout 1
Printer back layout 2
VACUUM
PUMP
MAIN
POWER
SOCKET
OUTLET
PRINTER
MAIN
POWER
SOCKET
INLET
VACUUM
PUMP INPUT
HOSE
CONNECTION
40MM
DIAMETER
MAIN POWER SWITCH
FOOT
SWITCH
OPTION
