Matrix UV Series User Manual

GENERAL INFORMATION
M A T R I X
1 8 0 6 / 1 8 0 6 C u b e j e t / 1 8 0 6 M o n s t e r j e t
Maximum print size Maximum substrate width 570mm (22,44in)
Maximum substrate length 1800 mm (70,86in)
Maximum substrate height 200mm (7,87in) Matrix1806, 400mm (15,74in) Cubjet1806, 930mm (36,61in)
Monsterjet1806
Print Piezzo inkjet [8 channels 180 nozzles each]
Resolution Adjustable from 720x720 up to 2880x1440 dpi
Ink configuration CMYK+WWCLCL, CMYK+WWWW, Optional
Ink System Bottles system 500ml [refillable]
Ink curing UV-LED adjustable output
Software Azon RIP software
OS Windows 10
Connection Ethernet
Power AC 100/230 V 50-60Hz
Printer size Width 1330 mm (52,36in)
Length 2720 mm (107,08in)
Height 1120 – 1750 mm (44,09-68,89in)
Weight 450 – 550 kg
azonprinter.com MATRIX GETTING STARTED
