Page #26 background image
Version 1.6 V Series © 2013 Matrix Fitness | www.matrixtness.com ENG 26
SPARE PARTS LIST
Drive Gear Parts
02 40 CrMo R E 08 Right crank
02 40 CrMo L E 08 Left crank
02 40 C S 08 Allen bolt M8x20
02 40 C MD20 08 BB assembly MD20
02 40 C 2 RS Ball bearing SKF 6004Z
Brake Parts
02 50 A Brake adjustment knob
02 50 06 Bell crank
02 50 04 Brake pad
02 50 03 A Upper brake rod
02 50 05 Lower brake rod
Flywheel
02 40 H Flywheel axle
02 40 02 Chain tensioner
02 40 H L Flywheel bearing 6001Z
02 40 08 V MX 12 V Series ywheel
Chain Guard
02 42 02 V MX 12 Outer chain guard
02 42 04 Plastic cover
02 42 01 E 08 Inner chain guard
02 42 03 V MX 12 Left cover
02 99 03 Allen bolt M4x15
Frame
02 99 50 V MX V Series frame
02 10 AV Vertical insert sleeve
02 20 04 Rubber stop handlebar tube
02 99 02 V LS Bottle holder
02 99 50 V MX Sticker set complete
Belt drive
02 40 BE Belt
Handlebar
02 30 01 V LS V Series handlebar
02 10 B V LS Pop pin adjustment knob
02 10 L Left fore/aft
Saddle Support
012VL-3125 SI Saddle
02 21 AK Saddle mounting bracket
02 21 01 V LS Horizontal & vertical
saddle support
02 20 02 Horizontal insert sleeve
02 10 L Lever fore/aft
02 10 V LS Pop pin adjustment lever
ENGDEU ESP
Pedals
01 40 A 2 Combi-Pedals (pair)
01 40 A 3 toe strap (pair)
Front Stabilizer
02 11 01 E 08 Front Stabilizer
02 11 B Stabilizer mounting kit
02 99 10 Front protection plates
02 11 A Transport wheel
02 11 06 Plastic end cap
Rear Stabilizer
02 11 V PVC gasket
02 11 02 E 08 Rear Stabilizer
02 11 06 Plastic end cover
02 11 05 B MYR Rubber foot stand
02 99 11 Rear protection plates
Matrix_V-Series_bike_1.6.indd 26 1/11/13 10:16 AM
