Matrix VS-S331 - Page 13

13
Q
R
9
Premium Kit (optional)
Step 10 Hardware
Description Qty
Q
R
Bolt (M8x60L)
Bolt (M8x35L)
4
2
Torque Value
Q
R
25 Nm / 18 ft-lb
15 Nm / 11 ft-lb
For more info, see weight stack
assembly manual.
ASSEMBLY COMPLETE!
1
2
NOTE:
This model uses collars to attach guide rods.
Weight Stack Hardware
Description Qty
1
2
Bolt (M8x16L)
Collar
4
4
