12
O
P
Step 9 Hardware
Description Qty
O
P
Bolt (M8x25L)
Flat Washer (Φ8.2)
4
4
Torque Value
15 Nm / 11 ft-lb
7 8
Torque Value
10 Nm / 7 ft-lb
