20
right at angles of 0° / 15° / 30° / 45°.
1. Remove the battery (7) from the device.
2. Loosen the screws at the bottom of the device
using the Allen wrench (13).
3. Slide the base plate to the rear until it can be
freely rotated.
4. Set the desired cutting angle. The number of
degrees to be set is engraved on the base plate.
5. Slide the base plate back to the front until the
toothing engages.
6. Tighten the screws at the bottom of the device
using the Allen wrench (13).
8.6 Mounting the rip fence (B11)
The rip fence can be fastened on both sides of
the device.
1. Remove the battery (7) from the device.
2. Loosen the locking screws (15) at the slot.
Make sure not to unscrew the locking screws
completely.
3. Slide the rip fence (10) into the slot with the
marking pointing up.
4. Move the rip fence (10) into the desired
position.
5. Tighten the locking screws (15).
8.7 Connecting the dust extraction system
(B12)
You can connect a vacuum cleaner to the device.
With the help of the adapter on the jig saw the
connection of a small hose diameter is possible.
Always use a special vacuum cleaner when
vacuuming harmful or toxic substances.
1. If required, attach the dust pipe to the
connection for the dust extraction system .
2. Connect a suitable vacuum cleaner (e.g.
industrial vacuum cleaner) to the dust extraction.
9. Technical data
Voltage supply: 20 V
Idling speed: 0-3000 min
-1
Cutting depth: Max. 100 mm
Battery pack
Rated voltage: 20V d.c.
Rated input current: 1500mAh
UK
charger
Input voltage: 220-240 V ~/50 Hz, 50W
Output voltage / current: 21V DC / 1800 mA
Sound and vibration
Sound and vibration values were measured in
accordance with EN 62841.
L
pA
: sound pressure level 85.2 dB(A)
K
pA
: uncertainty 5 dB(A)
L
WA
: sound power level 96.2 dB(A)
K
WA
: uncertainty 5 dB(A)
Wear ear-mus.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three
directions) determined in accordance with EN
62841.
Cutting wood
Vibration emission value a
h,B
= 10.44 m/s
2
K uncertainty = 1,5 m/s
2
Cutting sheet metal
Vibration emission value a
hM
= 5.42 m/s
2
K uncertainty = 1,5 m/s
2
Important!
The vibration value changes according to the area
of application of power tool and may exceed the
specied value in exceptional circumstances.
Keep the noise emissions and vibrations to a
minimum.
• Only use appliances which are in perfect
working order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
