Matrox
®
QuadHead2Go
™
Series Configuration Guide
46/48
at the bottom left of the video wall array.
If the array has a number of rows that’s divisible
by 4, place the final QuadHead2Go unit in 4x1.
Place the final QuadHead2Go unit in 2x1.
Example:
Reason
Most of the QuadHead2Go units will be in 2x2, and as many as
possible of the 4 outputs on a QuadHead2Go are used.
Exceptions
2x3, 4x3, and 6x configurations.
