CHARGING INDICATION (AE150E)
When the charger is being used, it shows LED lights as follows,
indicating the status of the charging.
NO AC Power (all lights off)
There is no AC power applied. Check the AC end.
STAND BY (green blinking only)
The clamps are not connected to battery properly.
CHARGING (both lights on)
The charger is charging the battery.
DEFECTIVE BATTERY (red lit only)
The battery cannot hold a charge. Immediate
replacement is recommended.
75% CHARGED (green lit & red blinking)
The battery is 75% charged and ready for load test or can
be returned to serve.
FULLY CHARGED (green lit only)
The battery is fully charged. The charger will shift to the
maintenance mode.
