INSTALLATION (PLEASE SEE SEPARATE SHEET FOR WALL MOUNT INSTRUCTIONS)
OPENING THE COVER
To open the cover insert a small
screwdriver (1) or similar implement into the
round opening at the base of the cover.
Use it to push the fastening connection
towards the left until the catch is released
(2). Gently lift the cover open to the
maximum angle of 100 degrees (3). DO NOT
force the cover to open further.
Once you have connected all your appliances
(see page 8), always secure the lid with the
closing screw (the closing screw is packed
together with the 2 blanking plugs).
Locking Screw
1
2
3
max. 100
o!
WARNING: ALWAYS TURN THE SWITCH BOX POWER
OFF AT THE MAINS ELECTRIC BEFORE OPENING
THE COVER. ALWAYS SECURE WITH CLOSING SCREW.
