06900 MULTI-PURPOSE GRINDER
CHANGING THE GRINDING STONE:
1.) DISCONNECT THE TOOL FROM THE POWER SOURCE.
2.) ROTATE THE STONE SLOWLY BY HAND WHILE DEPRESSING THE SHAFT LOCKING PIN
MECHANISM (LOCATED ON THE SIDE OF THE GUARD CASTING).
3.) WHEN THE PIN ENGAGES, LOCKING THE SHAFT, REMOVE THE NUT HOLDING THE STONE
AND FLANGES TO THE SHAFT
4.) INSTALL THE NEW STONE. BE SURE THAT THE FLANGES HAVE BEEN REPLACED AND
THAT THE GRINDING STONE IS EQUIPPED WITH A BLOTTER.
5.) TIGHTEN THE NUT ON THE SHAFT. DO NOT OVER TIGHTEN AS THIS MAY CAUSE THE
STONE TO FAIL WHILE IN USE.
6.) RELEASE THE LOCKING MECHANISM AND CHECK TO MAKE SURE IT IS RELEASED FROM
THE SHAFT BEFORE BEGINNING TO USE.
• REFER TO MANUFACTURER’S SPECIFICATIONS FOR TORQUE SETTINGS ON STONE
ATTACHMENT
