MAULE AEROSPACE TECHNOLOGY, INC.
MAINTENANCE MANUAL
FOR M-5-220C
Rev. B 21/38
1.
Main wheel bearings - Use aircraft quality bearing grease.
2.
Oleo shock struts – For P/N 4015B oleo spring, use New Holland No.134 hydraulic oil or Ford
Tractor No. ESN-M2C134-D. 10W30 engine oil may also be used. For P/N 4161B oleo spring
use API GL-4 or GL-5 85W-140 gear oil.
3.
Landing gear hinges – Use engine oil.
4.
Hydraulic brake reservoirs - Use Texaco Aircraft Hydraulic Oil 15 conforming to MIL-H-5606E,
or equivalent.
5.
Control Column - Apply light coat of graphite base lubricant to aileron balance chain, torque
tube and control guide. Use lightweight motor oil or LPS 2* on all other bearings.
6.
Use lightweight motor oil or LPS 2*:
• Control pulley bearings and control surface hinges
• Flap bellcrank and mechanism
• Aileron and flap hinge
• Elevator and trim tab
7.
Tailwheel - Good quality wheel bearing grease to tailwheel bearings through zerk fitting.
Same for fork spindle roller bearings, if necessary. See tailwheel maintenance section under
"Landing Gear, Wheels and Brakes".
*LPS 3 recommended for airplanes operating in a potentially corrosive environment.
(Applicable to Polyurethane paint on Ceconite fabric only)
(This aftermarket application is approved for this model - no M-5-220C's were manufactured with this covering and paint)
1. Small holes and damaged areas can easily be repaired without removing the existing
paint topcoat.
2. Trim the damaged area to a rectangular or circular shape.
3. Lightly scuff sand with #320 or #400 wet/dry sandpaper approximately 2 inches around
the repair area.
4. Mix one part gray urethane primer (catalyst) with two (2) parts gray urethane primer (2:1
ratio - 2 parts paint/1 part catalyst), mixing a very small amount only for coating the
sanded area around the repair.
5. Apply one coat (this may be brushed) to the sanded area slightly larger than the size of
