MAULE AEROSPACE TECHNOLOGY, INC.
MAINTENANCE MANUAL
FOR M-5-220C
Rev. B 6/38
DESIGN SPECIFICATIONS: (Cont’d)
Wings:
a. Airfoil Modified USA 35-B
b. Chord 63 inches
c. Incidence +30 minutes
d. Dihedral 1.2 degrees
e. Sweepback None
Areas:
a. Wing, Aileron and Flaps 157.9 sq.ft.
b. Ailerons (total) 12.8 sq.ft.
c. Flaps (total) 18.8 sq. ft.
d. Horizontal Stabilizer 14.2 sq. ft.
e. Elevators (including tab) 15.7 sq. ft.
f. Vertical Stabilizer 12.9 sq. ft.
g. Rudder …5.8 sq.ft.
h. Elevator Trim tab 1.0 sq. ft.
i. Rudder Tab .34 sq. ft.
FLUID CAPACITIES AND SPECIFICATIONS:
a. Main Fuel Tanks - Inboard - 100 Octane
Right Main Tank 21.5 gallons total
Left Main Tank 21.5 gallons total
Note: 1.5 gallons unusable fuel per 21.5 gallon main tank
b. Auxiliary Fuel Tanks - Outboard - 100 Octane
Right Auxiliary Tank 11.5 gallons
Left Auxiliary Tank 11.5 gallons
c. Engine Oil
(SAE 50 above 60°F, SAE 40 at 30° to 90°F, SAE 20 below
10°F ambient air temp. at sea level. Refer to Engine Manual for
AD Oil grades.)
8.8 qt.
d. Brakes (Texaco Aircraft Hydraulic Oil 15, MIL-H-5606E or equiv.)
1 pint
e. Landing Gear - For P/N 4015B oleo spring, use New Holland No.134 hydraulic
oil or Ford Tractor No. ESN-M2C134-D. 10W30 engine oil may also be used.
For P/N 4161B oleo spring use API GL-4 or GL-5 85W-140 gear oil.
2 pints
