Connecting the Two Sides
Step 1: Slide the (2) shells together. Make sure the rain guard at the top of the door
shell completely covers the flange of the other shell.
+ Clamp the (2) shells together to secure them while you drill holes
Step 2: Drill through dimple marks in the top (2) corners, tighten bolts by hand
Step 3: Drill through the remaining dimples down each side of the blind
Step 4: Tighten bolts by hand or with a 7/16” socket wrench
Step 5: Repeat steps 3-4 for the remaining dimples on the roof
DO NOT over tighten the bolts.
Part 5-Shooter GX 6-Shooter XL
Half Shell with Door 1 1 1
Half Shell with Windows 1 1 1
¼” x 1” Hex Bolts with Nuts 21 21 21
CONNECTING THE TWO SIDES CONNECTING THE TWO SIDES
